2.0 ton Electric Reach Truck HF-CQXD20

HUPER HF-CQXD20 Electric Reach Truck is engineered for higher load capacity and intensive material handling tasks. With a 2.0 ton rated load, robust welded steel structure, and advanced AC drive system, it delivers powerful and stable performance for high stacking and long-duty warehouse operations.

Get Latest Price Now

2.0 ton Electric Reach Truck HF-CQXD20 Features

  • Reinforced welded sheet metal body with enhanced anti-corrosion coating.
  • AC drive motor technology ensures high efficiency and low maintenance.
  • High-capacity deep-cycle lead-acid battery (2V210Ah × 12 cells, 240Ah).
  • Curtis and FORTON electrical control system for accurate travel control.
  • Integrated electrical system reduces failure points and downtime.
  • Intelligent high-frequency charger improves charging efficiency.
  • Dashboard battery indicator supports operational planning.
  • Designed for heavier loads and higher stacking requirements.
Send Inquiry Now
  • Specifications
  • Description
MODEL NO. HF-CQXD20
Performance 1 Maximum load capacity kg 2000
2 with load center at Q mm 500
3 Maximum lifting height H3 mm 3000
4 Reach distance E mm 610
5 Tiltiing angle (up/down) a/b °  3/5
6 Travel speed, with load/without load km/h 44846
7 Lifting speed, with load/without load mm/s 270/375
8 Ascend slope ability (without load ) % 15
9 Ascend slope ability (with load ) 3 minutes rated, 1.5Km/h and above 1.5Km/h % 10
10 Weight (with battery) kg 2900
Dimensions 11 Length Mast length L mm 1910
12 Overall length (frame not moved forward, including fork) L1 mm 2360
13 Overall length (frame moved forward, including fork) mm 2985
14 Width Overall width B mm 1270
15 Fork inside spacing mm 920
16 Frame mm 1270
17 Height Fork mm 310
18 Mast lowered height H1 mm 2100
19 Max height(mast lifted with backrest) H4 mm 3900
20 Overhead guard height H2 mm 2260
21 Front suspension distance Move the mast to the front X mm 160
22 Standing plate height mm 340
23 Wheel base Y mm 1525
24 Minimum Ground Clearance mm 80
25 Wheel tread Front wheel mm 1160
26 Rear wheel mm 760
27 Fork size width/thickness/length l/b/s mm 122/40/1070
28 For outside distance Min./Max. mm 250-820
29 Min.Turning radius Wa mm 1820
30 Min intersecting aisle width (including 200mm clearance) 1000*1200 tray,1200 direction to use fork mm 2820
31 Min intersecting aisle width (including 200mm clearance) 1000*1200 tray,1000 direction to use fork mm 2900
32 Min intersecting aisle width (including 200mm clearance) 1100*1100 tray mm 2855
Tires 33 Qty Load wheel/drive wheel/balance wheel 2002/1/2
34 Tire Load wheel mm φ267×114
35 Drive wheel mm φ343×135
36 Balance wheel mm φ180×55
37 Material PU
Driving system and controller 38 Driving motor Type AC motor
39 Power kw 6.5
40 Liftging motor Type AC motor
41 Power kw 12
42 Steering motor Type AC motor
43 Power kw 0.7
44 Controller Walking and hydraulic control Curtis controller
45 Steering controller Curtis controller
46 Brake type Electromagnetic brake
47 Battery Voltage V 48
48 Capacity AH 400
49 Weight kg 710
50 Battery change methods Side pull type
51 Charger Type Outside
52 Input Three phase 380V
53 Output 48V60A

HF-CQXD20 focuses on strength, stability, and endurance. Its reinforced welded body structure enhances rigidity and load-bearing capability, making it suitable for higher-weight pallets and demanding warehouse environments.

The AC drive motor provides consistent power output without brush maintenance, while the Curtis control system ensures smooth speed regulation and safe handling under load. The high-capacity battery system supports extended working hours, ideal for multi-shift operations.

With an integrated electrical layout, the HF-CQXD20 simplifies inspection and maintenance, reducing long-term operating costs. The intelligent charger and clear battery monitoring system further improve daily operational efficiency.

https://www.huperforklift.com/wp-content/uploads/2025/08/huper-index-play.jpg
Download Catalogue
  • Electric Pedestrian Pallet Stacker HF-CDD15
  • Electric Pedestrian Pallet Stacker HF-CDD15
  • Lithium Electric Counterbalance Forklift Truck
  • Huper Electric Pallet Stacker detail

HUPER Electric Reach Truck Quality Control

HUPER applies rigorous quality control standards for HF-CQXD20, including structural load testing, electrical safety checks, and battery endurance testing. Each unit is verified to meet export-grade performance and durability requirements.

Full Support on Your Electric Reach Truck

HUPER offers comprehensive OEM/ODM services and technical support for HF-CQXD20. Distributors and enterprise clients benefit from flexible configuration options, spare parts availability, and professional after-sales assistance.

HUPER Golf Carts Warranty
1 Year Warranty
Electric reach truck From HUPER Are Available With 12 Months Extended Warranty; You Can Also Get Free Parts And Repairs.
huper cbd power battery
Optional Configuration
There Are Tons Of Optional Configurations When You Get Electric Pallet Truck, The Customization Options Depend On The Electric reach truck Application.
huper logo
Maintenance
HUPER Made Electric reach truck Have Easy Maintenance, Durable Parts, And Detailed Manuals Ensures Easy Care For Your Electric reach truck.
HUPER Golf Carts Online Support
Online Support
Accessing Support At HUPER Is Easy And Fast, The Robust Customer Care Agents Are Accessible Via Different Channels Like Email, Telephone, And Whatsapp.

Related Electric Reach Truck

In addition to the HF-CQXD20 , HUPER supplies electric reach trucks from 1.2 tons up to 2.5 tons, plus a wide range of material handling equipment such as electric pallet trucks, pallet stackers, tow tractors, and counterbalance forklifts. This complete product portfolio supports distributors and end-users with integrated handling solutions.

Hand Pallet Truck HF-CBY30
3.0 ton Hand Pallet Truck HF-CBY30
HF-CBY30 Hand Pallet Truck is a heavy-duty manual low lifter with a rated load capacity of 3,000 kg. Its compact body and lightweight frame allow operation in narrow aisles and elevators.
lectric Counterbalance Forklift Truck HF-CPD35
3.5 Ton Electric Counterbalance Forklift Truck HF-CPD35MA7
HUPER HF-CPD35ma7 is a 4-wheel counterbalance electric forklift with a rated load capacity of 3.5 tons and 500mm load center.
Electric Pallet Truck HF-CBD20
2.0 Ton Electric Pallet Truck HF-CBD20
HUPER HF-CBD20 Electric Pallet Truck is a professional solution for handling pallets up to 2.0 tons.
Electric Pallet Stacker HF-CDD15HE
1.5 Ton Electric Pallet Stacker HF-CDD15HE
HUPER CDD15HE Electric Pallet Stacker is a robust and efficient material handling solution designed for warehouses, factories, retail distribution, and logistics hubs.

Send Your Inquiry Now

HUPER HF-CQXD20 Electric Reach Truck | 2.0 Ton Stand-On Reach Truck Manufacturer



With over two decades of manufacturing expertise, HUPER has built a strong reputation as a reliable supplier of electric material handling equipment for global markets. The HF-CQXD20 electric reach truck represents HUPER’s solution for customers requiring higher capacity, durability, and long-duty performance.

By combining a reinforced steel body, AC drive technology, advanced Curtis control systems, and intelligent charging solutions, the HF-CQXD20 meets the demands of modern warehouses with heavy pallet loads and high throughput requirements.

Supported by strict quality control and OEM/ODM capability, HUPER delivers dependable reach truck solutions to distributors and large end users worldwide.
