1.5 ton Electric Pallet Stacker HF-CDD15
HUPER HF-CDD15 Electric Pedestrian Pallet Stacker is a compact and high-performance solution built for tight warehouse aisles and general industrial environments. With a rated capacity of 1500 kg and a 600 mm load center, it is powered by a 24V DC permanent-magnet drive motor and supported by a 80Ah deep-cycle maintenance-free battery. The integrated charger, reinforced fork legs, and CURTIS control system ensure smooth operation and stable lifting performance. The HF-CDD15 is ideal for warehouses, factories, logistics centers, and retail distribution where efficient and flexible material handling is required.
1.5 ton Electric Pallet Stacker HF-CDD15 Features
- Compact size, lightweight chassis, and agile handling suitable for narrow aisles and container operations
- Release braking, reverse braking, and triple emergency braking for enhanced safety
- Permanent-magnet drive motor with strong performance and low heat generation
- Built-in charger and maintenance-free gel battery for convenient daily use
- CURTIS control system with precise, efficient, and stable operation
- Reinforced fork leg structure for high rigidity and resistance to deformation
- User-friendly dashboard with battery indicator and hour meter
- Simplified structure for easy maintenance and long service life
- Specifications
- Description
- HUPER Electric pallet stacker Detail
| Features | 1.1 | Manufacturer’s type designation | HUPER | ||
| 1.2 | Model | HF-CDD15 | |||
| 1.3 | Power Type | Electric | |||
| 1.4 | Type of operation | Pedestrian | |||
| 1.5 | Steering Mode | Mechanical | |||
| 1.6 | Load capacity/rated load | Q | kg | 1500 | |
| 1.7 | Load center distance | C | mm | 500 | |
| 1.8 | Wheelbase | y | mm | 1240 | |
| Weight | 2.1 | Total Weight(with | kg | 560 | |
| 2.2 | Axle Load(laden):Drive side/Load-bearing side | kg | 750/1310 | ||
| 2.3 | Axle Load(unladen):Drive side/Load-bearing side | kg | 400/160 | ||
| Dimension | 3.1 | Overall Length | L1 | mm | 1755 |
| 3.2 | Overall Width | W1 | mm | 800 | |
| 3.3 | Lift Height | h1 | mm | 3000 | |
| 3.4 | Lowered mast height | h2 | mm | 2050 | |
| 3.5 | Extended mast height | h4 | mm | 3520 | |
| 3.6 | Fork Dimension | l/e/s | mm | 1150×160×60 | |
| 3.7 | Width of Fork | b2 | mm | 560/685 | |
| 3.8 | Min.Fork Height | h3 | mm | 85 | |
| 3.9 | Ground Clearance at center of wheelbase（Min） | m1 | mm | 30 | |
| 3.10 | Height of Operating Handlebar(Min./Max) | h14 | mm | 1290 | |
| 3.11 | Turning Radius | Wa | mm | 1435 | |
| 3.12 | Aisle width for lengthways(Pallet size 1000*1200)(Pedal retracted/expanded) | mm | 2275 | ||
| 3.13 | Aisle width for lengthways(Pallet size 800*1200)(Pedal retracted/expanded) | mm | 2215 | ||
| Tyre | 4.1 | Tyre Type | Polyurethane | ||
| 4.2 | Tyre Size(Front) | mm | φ80*70 | ||
| 4.3 | Tyre Size(Auxiliary wheel) | mm | φ115*55 | ||
| 4.4 | Tyre Size(Driving Wheel) | mm | φ210*70 | ||
| 4.5 | Wheels Quantity, front/rear (x=driving wheels) | 2/1x+1 | |||
| Function | 5.1 | Traveling Speed(laden/unladen) | Km/h | 3.2/3.3 | |
| 5.2 | Lifting Speed(laden/unladen) | mm/s | 100/135 | ||
| 5.3 | Lowering Speed(laden/unladen) | mm/s | 155/150 | ||
| 5.5 | Max.Gradient performance s2 5min (laden/unladen) | % | 3/5 | ||
| 5.6 | Service Brake Type | Electromagnetic | |||
| 5.7 | Parking Brake Type | Electromagnetic | |||
| Power | 6.1 | Drive Motor Rating(AC)S2-60min | kW | 0.75 | |
| 6.2 | Lift Motor Rating(DC)S3-15% | kW | 2.2 | ||
| 6.3 | Battery Voltage/Capacity K5 | V/Ah | 24/80 | ||
| 6.4 | Battery Weight | kg | 50 | ||
| Others | 7.1 | Controller Brand | CURTIS | ||
| 7.2 | Controller Model | 1212P | |||
| 7.3 | Sound level at driver’s ear according to EN 12 053 | dB | 70 | ||
HF-CDD15 delivers a 1500 kg load capacity with a compact body width (790 mm) that allows mobility in narrow aisles and confined warehouse spaces. Its 750W permanent-magnet drive motor ensures stable traction, while the CURTIS controller enhances operational accuracy. The stacker is equipped with LEOCH 12V*2 maintenance-free deep-cycle batteries and an intelligent high-frequency charger, offering 3–5 hours of effective operating time. Designed for durability, the reinforced mast and strengthened fork legs provide reliable load support, making it suitable for warehouse storage, industrial workshops, supermarkets, logistics hubs, and small-space material handling scenarios.
HUPER Electric pallet stacker Quality Control
HUPER performs strict IQC, PQC, and QA inspections throughout production to ensure every HF-CDD15 meets international standards. Core components—including batteries, masts, gearboxes, and chassis structures—are manufactured in-house to maintain stable quality and cost control. Each unit undergoes full load testing before shipment, ensuring reliability for global B2B customers and distributors.
Full Support on Your Electric pallet stacker
HUPER provides technical consultation, spare parts supply, and international after-sales support. Distributors benefit from stable production capacity, export-ready documentation, and fast delivery. Professional guidance ensures the HF-CDD15 operates efficiently in various working environments, supporting long-term cooperation with global partners.
Related Electric pallet stacker
In addition to the HF-CDD15 Electric Pallet Stacker, HUPER offers a full range of material handling equipment: Electric Pallet Truck for efficient horizontal transport/Electric Reach Truck for high-rack operations/Electric Counterbalance Forklift for versatile indoor and outdoor handling/Electric Tow Tractor for towing and logistics applications/Hand Pallet Truck for cost-effective manual operations.
Send Your Inquiry Now
1.5 Ton Electric Pallet Stacker HF-CDD15 | HUPER Electric Pallet Stacker Manufacturer
HUPER is a leading manufacturer of electric material-handling equipment in China, supplying global markets with reliable and cost-effective solutions. With over 20 years of industry experience, the company operates a large-scale production base of more than 200,000 square meters, supported by a team of 50 engineers and 800 skilled workers. HUPER specializes in Electric Pallet Stackers, Electric Pallet Trucks, Electric Forklifts, Electric Reach Trucks, Electric Tow Tractors, and related equipment, providing OEM/ODM services to global distributors and industrial customers.
The HF-CDD15 Electric Pedestrian Pallet Stacker is developed to meet the needs of modern warehousing and logistics operations. Featuring a compact structure and agile handling, it is especially effective in narrow aisles, retail backrooms, and small warehouse spaces where space utilization is critical. Its chassis width allows operators to maneuver efficiently even inside containers, rack aisles, and tight storage corridors.
Powered by a permanent-magnet drive motor, the HF-CDD15 ensures strong torque output while maintaining low heat generation, which significantly reduces wear and improves energy efficiency. The CURTIS control system enhances precision during lifting and traveling, offering stable acceleration and reliable braking performance. Multiple safety functions—including release braking, reverse braking, and emergency braking—ensure optimal protection during intensive operations.
The stacker is designed with a reinforced mast and strengthened fork legs to support long-term heavy use. Its LEOCH maintenance-free deep-cycle batteries provide dependable operating hours of 3–5 hours, suitable for daily warehouse tasks. The built-in high-frequency intelligent charger eliminates the need for external charging equipment, improving convenience and reducing maintenance complexity.
Applications for the HF-CDD15 include warehouse storage, industrial workshops, logistics distribution, retail inventory handling, manufacturing production lines, and small business operations requiring efficient material movement. Its quiet operation and compact body also make it suitable for supermarkets, airports, freight terminals, and commercial supply chains.
HUPER’s manufacturing advantage comes from its high level of vertical integration. The company produces core components—including gearboxes, batteries, masts, controllers, and chassis structures—internally, ensuring consistent quality and competitive pricing. A full quality inspection system, combining IQC, PQC, and final QA testing, guarantees each stacker meets international performance and safety standards.
By offering both HUPER-branded products and customized OEM/ODM solutions, the company supports global distributors, wholesalers, and enterprise customers in developing local markets and enhancing product competitiveness. With reliable product durability, stable supply capacity, and strong engineering support, HUPER has become a trusted supplier in the global material-handling industry.
The HF-CDD15 stands out as a compact, safe, and efficient Electric Pallet Stacker designed for versatile industrial applications. Combined with HUPER’s full range of Electric Pallet Trucks, Electric Forklifts, and Electric Reach Trucks, it provides a complete solution for modern warehousing operations and international B2B buyers.
